3) TEMPERATRUE CHART - REF AND DEF SENSOR
Troubleshooting
TEMP RESISTANCE VOLTAGE
-39°F( -40°C) 225.1 4.48 V
-30°F(-35°C) 169.8 4.33 V
-21°F(-30°C) 129.3 4.16 V
-13°F( -25°C) 99.3 3.95 V
-4°F(-20°C) 76.96 3.734 V
5°F(-15°C) 60.13 3.487 V
14°F( -10°C) 47.34 3.22 V
23°F( -5°C) 37.55 2.95 V
32°F( 0°C) 30 2.67 V
41°F(+5°C) 24.13 2.40 V
50°F(+10°C) 19.53 2.14 V
59°F( +15°C) 15.91 1.89 V
68°F( +20°C) 13.03 1.64 V
77°F( +25°C) 10.74 1.45 V
86°F( +30°C) 8.89 1.27 V
95°F(+35°C) 7.4 1.10 V
104°F( +40°C) 6.2 0.96 V
80
