Page #6 background imageLoading...
Page #6 background image
Copyright ©2009 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
- 6 -
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement
.
1. Application Range.
1) This spec sheet is applied all of the LCD TV with LD93A
chassis.
2) Not included spec and each product spec in this spec sheet
apply correspondingly to the following each country standard
and requirement of Buyer
2. Specification
Each part is tested as below without special appointment
1) Temperature : 25±5°C(77±9°F) , CST: 40±5°C
2) Relative Humidity : 65±10%
3)
Power Voltage : Standard input voltage (100~240V@50/60Hz)
*Standard Voltage of each product is marked by models
4) Specification and performance of each parts are followed
each drawing and specification by part number in accordance
with BOM.
5) The receiver must be operated for about 20 minutes prior to
the adjustment.
3.Test method
1) Performance :
LGE TV test method followed
2) Demanded other specification
- Safety : CE,IEC specification
- EMC : CE,IEC specification
4. Electrical Specification
4.1 Module Specification
Model Market Appliance
Safety : IEC/ EN60065
Mx62D
EU
EMI :EN55013
(PAL Market)
EMS : EN55020
No Item Specification Unit Remark
1 Type TFT Color LCD Module
2 Diagonal Size 21.53 inches diagonal
3 Active Display area 476.64( H) 268.11(V) mm
4 Outline Dimension 495.6( H) x 292.2( V) x16.5( D) mm Typ. (Without Inverter)
5 Aspect Ratio 16: 9
6 Pixel Number 1920 x RGB x 1080 pixel
7 Pixel Pitch 0.248( H) x 0.248( V) mm
8 Color arrangement RGB vertical Stripe
9 Color Depth 16.7M color (6bit with A- FRC)
10 Electrical Interface LVDS 2Port
11 Surface Treatment Hard coating( 3H) & Anti- glare( Haze 25)
12 Operating Mode Normally White
13 Backlight Unit 4 CCFL (4 lamps)
14 Response Time Rising Time : 1.3 + Falling Time : 3.7 ms Typ.
15 Color Gamut 72%
- M2262D- PZL : LGD / LM215WF- TLA1( P/ N : EAJ60156901)
