- 7 -

Only for training and service purposes

LGE Internal Use Only

No Item Specification Remarks

DTV &Analog- UK,France,Germany,Spain,Sweden,Finland,

Italy,Netherland,Belgium,Czech Luxemburg,Greece,

1 Market EU(PAL Market-26Countries) Denmark,Austria,Hungary,Switzerland,Croatia,Turkey

Analog Only -Poland,Portugal,Norway,Bulgaria,Serbia,

Slovenia,Russia,Romania

1) PAL-BG

2) PAL-DK

2 Broadcasting system 3) PAL-I/I’

4) SECAM L/L’

5) DVB-T

3 Receiving system

Analog : Upper Heterodyne

Digital : COFDM

4 Scart Jack (2EA) PAL,SECAM

Scart 1 Jack is Full scart and support RF-OUT(ATV)

Scart 2 jack is Half scart and support MNT/DTV-OUT.

5 Component Input (1EA) Y/Cb/CrY/Pb/Pr

6 CVBS Input (1EA) PAL,SECAM,NTSC 4 System(Rear):PAL50,SECAM,NTSC,PAL60

7 RGB Input RGB-PC Analog(D-SUB 15Pin)

8 DVI Input DVI-D Digital

9 HDMI Input (2EA)

HDMI1-DTV 1ea(Rear),1ea(Side)

HDMI2-DTV HDMI version 1.3 Support HDCP /Not support PC

10 Audio Input (3EA) RGB/DVI Audio, Component, CVBS L/R Input

11 SPDIF out (1EA) SPDIF out

12 Earphone out (1EA)

Antenna,AV1,AV2,AV3,Component,

RGB,DVI,HDMI1,HDMI2

13 USB (1EA) Picture,Music Software Update +Picture +Music

14 RS-232C (1EA) Commercial Mode

5. General specification

5.1 TV

No Item Specification Unit Remark

1 Type TFT Color LCD Module

2 Diagonal Size 21.53 inches( 546.86mm) diagonal

3 Active Display area 476.64( H) 268.11(V) mm

4 Outline Dimension 495.6( H) x 292.2( V) x16.35( D) mm Typ. (Without Inverter)

5 Aspect Ratio 16: 9

6 Pixel Number 1920 x RGB x 1080 pixel

7 Pixel Pitch 0.248( H) x 0.248( V) mm

8 Color arrangement RGB vertical Stripe

9 Color Depth 16.7M color (6bit with A- FRC)

10 Electrical Interface LVDS 2Port

11 Surface Treatment Hard coating( 3H) & Anti- glare( Haze 25)

12 Operating Mode Normally White

13 Backlight Unit 4 CCFL (4 lamps)

14 Response Time Rising Time : 3.8 + Falling Time : 1.2 ms Typ.

15 Color Gamut 72%

- M2262D- PZL : AUO / M215HW01- V0( P/ N : EAJ55729601)
