5.2 RGB
No Item Specification Remark
1 Supported Sync.Type Separate Sync.,Digital
Horizontal 30~83kHz
Analog
Vertical 56~75 Hz
2 Operating Frequency
Horizontal 30~83kHz
Digital
Vertical 56~75 Hz
Max. 1366 x 768 @60Hz
Analog
Recommend 1360 x 768 @60Hz
Max. 1366 x 768 @60Hz
M1962D
Digital
Recommend 1360 x 768 @60Hz
Max. 1600 x 900 @60Hz
3 Resolution
Analog
Recommend 1600 x 900 @60Hz
Max. 1600 x 900 @60Hz
M2062D
Digital
Recommend 1600 x 900 @60Hz
Max. 1920 x 1080 @60Hz
Analog
Recommend 1920 x 1080 @60Hz
M2262D/M2362D/M2762D
Max. 1920 x 1080 @60Hz
Digital
Recommend 1920 x 1080 @60Hz
4 Input Voltage Voltage :100 ~240 Vac,50 or 60Hz
5 Inrush Current Cold Start :50 A /Hot :120 A
Operating Condition Sync (H/V) Video LED Wattage
On/On Active Blue 50 Max.
M1962D
On/On Active Blue 40 Typ.
On/On Active Blue 60 Max.
M2062D
On/On Active Blue 50 Typ.
6 Power On On/On Active Blue 60 Max.
S/W Mode
M2262D
On/On Active Blue 53 Typ.
On/On Active Blue 60 Max.
M2362D
On/On Active Blue 55 Typ.
On/On Active Blue 120 Max.
M2762D
On/On Active Blue 100 Typ.
Off/On
Sleep mode
On/Off
Off Amber 1W RGB
Off mode - Off Off 0.5W
19”LGD :50,000 Hours(min)
20”CMO :40,000 Hours(min)
Lamp 20”LGD :50,000 Hours(min)
7 MTBF 50,000 HRS with 90%Confidence level Life 22”AUO :40,000 Hours(min)
22”LGD :50,000 Hours(min)
23”LGD :50,000 Hours(min)
27”LGD :50,000 Hours(min)
8 Using Altitude 5,000 m (for Reliability) 3,000m(for FOS)
9 Operating Environment
Temp :10°C ~35°C
Humidity :20 %~80 %
10 Storage Environment
Temp :-10°C ~60°C non condensing
Humidity :5 %~90 %non condensing
