POWER ON
FLD no disc status
Remote control ‘
’ + Front ‘STOP’
push same timing during 5s
FLD ‘OP-0….
Move to appropriate position and
make changes with remote control.
(
,
,
/
■
, REPEAT )
Press STOP key
FLD ‘write ok’
Remote control ‘
’ +
Front ‘STOP’ push same timing
FLD ‘E2P CLR’
Completed
NAME
OP0
OP1
OP2
OP3
OP4
OP5
OP6
OP7
OP8
OP9
DETECT NEW
EEPROM
(OPTION EDIT
SCREEN)
HEX
05
00
00
00
00
69
90
07
D0
09
1-6
SERVICE INFORMATION FOR EEPROM
6
8
Table of Contents
Section 1 Summary
3
Table of Contents
3
Servicing Precautions
4
Esd Precautions
6
Service Information for Eeprom
7
Program Download Guide
8
Specifications
11
Section 2 Cabinet & Main Chassis
12
Disassembly and Assembly for Mechanism Deck (CDM-H1803)
13
Order of Disassembly for Mechanism Deck
14
Cable7
15
Order of Assembly for Mechanism Deck
18
Exploded Views
22
Cabinet and Main Frame Section (Mcv1306)
22
Mechanism Deck Section (CDM-H1803)
23
Packing Accessory Section
24
Speaker Section
25
Section 3 Electrical
28
Training Master
29
No Sound from Speakers
29
No Sound in Aux Function
30
No Sound in Port. in Function
31
No Sound in Ipod Function
32
No Sound in Am/Fm Function
33
No Sound in CD Function
34
No Sound in Usb Function
36
No Power
37
One Point Repair Guide
38
No Power
38
No Booting When Power on the Set
40
Vfd Is Not Displayed When Power on the Set
41
No Operation of MD
43
No Sound
49
Electrical Troubleshooting Guide
56
Power Supply on Smps Board
56
System Part
60
No Audio Part
61
Digital Audio Amp Check
66
Waveforms
67
Wiring Diagram
70
Block Diagrams
71
Overall Block Diagram
71
Smps Block Diagram
72
Power Block Diagram
73
Circuit Diagrams
74
Smps Circuit Diagram
74
Micom Circuit Diagram
75
Pwm Circuit Diagram
76
Amp Circuit Diagram
77
Dsp Circuit Diagram
78
Rf Servo Circuit Diagram
79
Adc Circuit Diagram
80
Beat Box Circuit Diagram
81
Vfd Circuit Diagram
82
Volume Circuit Diagram
83
Usb Circuit Diagram
84
Ipod Circuit Diagram
85
MIC Circuit Diagram (Optional Part)
86
Circuit Voltage Chart
87
Printed Circuit Board Diagrams
89
Main P.C.board
89
Smps P.C.board
91
Vfd P.C.board
92
Volume P.C.board
93
Usb P.C.board
94
Ipod P.C.board
94
MIC P.C.board (Optional Part)
94
