3. CAPACITORS ON MAIN BOARD 4. CAPACITORS ON SMPS BOARD
3-79 3-80
No. Location Value Capacitor (uF) Voltage Spec. Measured voltage
01 C111 47uF 16V 3.37V
02 C145 2.2uF 16V 3.37V
03 C124 1000uF 6.3V 3.38V
04 C109 1000uF 6.3V 3.38V
05 C808 47uF 16V 1.19V
06 C529 100uF 16V 3.30V
07 C530 470uF 16V 5.66V
08 C531 470uF 16V 5.65V
09 C533 470uF 16V 3.28V
10 C706 10uF 16V 11.92V
11 C746 10u 16V 11.92V
12 C786 10uF 16V 11.92V
13 C713 470uF 100V 47.7V
14 C734 470uF 100V 47.7V
15 C753 470uF 100V 47.7V
16 C774 470uF 100V 47.7V
17 C793 470uF 100V 47.7V
18 C784 470uF 100V 47.7V
19 C527 47uF 16V 1.19V
20 C550 47uF 16V 1.19V
21 C570 10uF 16V 3.27V
22 C525 47uF 16V 3.27V
23 C482 100uF 16V 1.65V
24 C462 47uF 16V 3.27V
25 C467 3.3uF 50V 1.65V
26 C492 47uF 16V 3.27V
27 C405 470u 16V 1.57V
28 C4H6 100uF 6.3V 1.57V
29 C406 100uF 6.3V 3.27V
30 C485 220uF 16V 5.11V
31 C221 100uF 16V 3.28V
32 C235 10uF 16V 5.7V
33 C231 47uF 16V 5.1V
34 C221 100uF 16V 5.1V
35 C210 10uF 16V 2.55V
36 C660 47uF 16V 3.31V
37 C657 47uF 16V 5.12V
38 C655 10uF 16V 2.56V
39 C681 1uF 50V .3V
40 C679 100uF 16V 11.25V
41 C676 22uF 16V 1.96V
42 C122 100uF 16V 3.31V
43 C620 100uF 6.3V 1.25V
44 C621 1000uF 6.3V 3.30V
45 C682 1000uF 6.3V 3.30V
46 C601 100uF 16V 3.31V
47 C3U25 100uF 16V 5.1V
No. Location
Value Capacitor
(uF)
Voltage Spec.
100V-10% 240V/50Hz+10%
Measured voltage Measured voltage
01 C903 1000uF 315V 122.3V 190V
02 C904 1000uF 315V 123.9V 180.7V
03 C905 47uF 450V 245.9V 370.1V
04 C912 47uF 50V 18.47V 18.59V
05 C914 47uF 50V 12.68V 13.8V
06 C908 47uF 50V 15.34V 15.33V
07 C931 330uF 16V 4.81V 4.8V
08 C932 100uF 50V 31.96V 31.98V
09 C933 1000uF 16V 5.75V 5.75V
10 C935 1000uF 25V 12.63V 12.62V
11 C942 100uF 16V 11.99V 11.98V
12 C953 2200uF 80V 47.9V 48.1V
