LG MU-42PM20

Owner’s Manual 7
Introduction
Controls
Controls
Front Panel Controls
Front Panel Controls
- This is a simplified representation of a typical front panel.
The Front Panel Controls shown here may be somewhat different from your monitor.
MU-42/50PM10/11 series
MU-42/50PM20 series
ON/OFF
VOL
MENU
INPUT SELECT
ON/OFF
1 2 3 4 5 6
1
4
5
6
2
3
1. Main Power Button
2. Remote Control Sensor
3. Power Standby Indicator
Illuminates red in standby mode. Illuminates green when the
Monitor is turned on.
4. INPUT SELECT Button
5. MENU
Displays on screen menus one by one.
Exits the current menu.
Memorizes menu changes.
6.
DD
/
EE
Selects a menu option.
FF
/
GG
(Volume Up/Down)
Increases/decreases sound level.
Adjusts menu settings.
