LG Multi V 5

DOASOperation
Followinginstallation,DOASConfigurationandtestingincludestheprocess
identifiedbelow.
6.LGMVdata
LGSplitDOASSetUpReferenceGuide
DOASUnitsetsitsfirsttargetbasedon
OATemperatureCondition.
TheUnitwillthenperiodicallychangeits
targetPressurebasedonthedifference
betweenitstargetTemperatureand
currentSupplyTemperature.
DefaultControlCycleis180sec
andevery180secDOASunitsendsa
TargetPressurebasedontheTargetand
CurrentTemperaturedifference.
DOASandODUstatuscanbemonitoredbybothWebUIandLGMV
DOASUnitstatusisshownatIDUinfo.
CompactDOAS
‐ IDU1:MainCoil
‐ IDU2:ReheatCoil
RooftopDOAS
‐ IDU1:MainCoil#1
‐ IDU2:ReheatCoil
‐ IDU3:RecoveryCoil
‐ IDU4:MainCoil#2
[Cooling/Dehumidification] [Heating]
