LG MULTI V ARNU Series User Manual

- 26 -
Copyright ©2010 LG Electronics. Inc. All right reserved.
Only for training and service purposes
LGE Internal Use Only
Dimensions
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
CHASSIS CODE: TQ
Ceiling Cassette 4-way
ARNU15GTQ*2 ARNU18GTQ*2
Name
1 Liquid pipe connection
Unit size(15k, 18k):Ø6.35
2 Gas pipe connection
Unit size(15k, 18k):Ø12.7
3 Drain pipe connection 4 Power supply connection 5 Air discharge grill 6 Air suction grill
Number Descripition
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
(unit : mm)
570
570
517
68
174
517
461
523
30 19
142.5
165
63
95.5
79
48
125 59.5
570
76
94
256
2
4
3
1
Branch Duct Connection
R35
700
22.5
380(Air outlet hole)
473 700
376(Inlet Grille)
4R20
5
6
B ARROW VIEWA ARROW VIEW
B
A
VP25(Φ32)
CEILING OPENING
500mm or more*
500mm or more*
• REQUIRED SPACE
500mm or more*
500mm or more*
