Dimensions
Display & signal receiver
Part Name
Front panel
Air suction grille
Installation plate
Knockout hole
5
No.
2
4
3
1
Remark
Note
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
3
1
2
4
299
48
93
281
122
200
1107
804
10
63
53
58
72
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
CHASSIS CODE: S8
ART COOL Mirror
ARNU18GS8*2
ARNU24GS8*2
(unit : mm)
