3. Dimensions
Dimensions
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea www.lgeaircon.com
CHASSIS CODE: B1/B2
Ceiling Concealed Duct (Low Static)
ARNU073B1G2 ARNU093B1G2 ARNU123B1G2 ARNU153B1G2 ARNU183B2G2 ARNU243B2G2
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
Name
1
Liquid pipe connection
2
Gas pipe connection
3
Drain pipe connection
4
Power supply connection
5
Air discharge
6
Air suction
Number Descripition
[Unit : mm(inch)]
Unit size(7k,9k,12k,18k):ø6.35(1/4) Unit size(24k):ø9.52(3/8) Unit size(7k,9k,12k,18k):ø12.7(1/2) Unit size(24k):ø15.88(5/8)
A
383(15-1/16)
575(22-5/8)
161(6-5/16)
14(1/2)
154(6)
190(7-7/16)
18(3/4)
18(3/4)
B
C
13(1/2)
D
820
(32-5/16)
ABCD
ARNU073B1G2 ARNU093B1G2 ARNU123B1G2 ARNU153B1G2
ARNU183B2G2 ARNU243B2G2
728
(28-11/16)
856
(33-11/16)
794
(31-5/16)
1100
(43-5/16)
1008
(39-11/16)
1131
(44-9/16)
1072
(42-3/16)
[Unit : mm(inch)]
LG Electronics USA, HVAC Division 1000 Sylvan Avenue, Englewood Cliffs, NJ 07632 www.lgusa.com / www.lghvac.com
2
1
190(7-7/16)
65(2-1/2)
60(2-3/8)
277(10-7/8)
216(8-1/2)
24(11/12)
1
3
4
2
5
6
