76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
www.lgeaircon.com
CHASSIS CODE: B8
Ceiling Concealed Duct (High Static)
URNU763B8A2
URNU963B8A2
Note
1. Unit should be installed in compliance with the installation manual
in the product box.
2. Unit shall be grounded in accordance with the local regulations or
applicable national codes.
1
Liquid pipe connection
2
Gas pipe connection
3
Drain pipe connection
4
Power supply connection
5
Air discharge
6
Air suction
Descripition
[Unit : mm(inch)]
Unit size(76k,96k):ø9.52(3/8)
Unit size(76k):ø19.05(3/4)
Unit size(96k):ø22.2(7/8)
1,562(61-7/13)
1,622(63-11/13)
688(27)
688(27)
560(22)
64(2-7/13)
30(1-3/16)
1,220(48)
329(12-15/16)
320(12-5/8)
329(12-15/16)
318(12-7/13)
293(11-7/13)
460(18-1/13)
460(18-1/13)
290(11-7/16)
161
(6-3/8)
70(2-3/4)
120(4-3/4)
99(3-7/8)
14
0
(
5
-9/16)
440(17-3/8)
20(3/4)
1,396(54-15/16)
115(4-9/16)
LG Electronics USA, HVAC Division
1000 Sylvan Avenue, Englewood Cliffs, NJ 07632
www.lgusa.com / www.lghvac.com
3
2
1
4
6
5
1,562(61-1/2)
64(2-1/2)
70(2-3/4)
60(2-3/8)
122(4-7/8)
358(14)
109(4-1/4)
68(2-5/8)
18(3/4)
58(2-1/4)
