Dimensions
76, Seongsan-dong, Changwon City, Gyeongnam,
641-713, Korea
CHASSIS CODE: S5
Wall Mounted
ARNU18GS5*2 ARNU24GS5*2
WModel
ARNU18GS5*2 ARNU24GS5*2
HD
1090 300 178
Note
1. Unit should be installed in compliance with the installation manual in the product box. 2. Unit shall be grounded in accordance with the local regulations or applicable national codes.
(unit : mm)
281
804
Front panel
Air discharge
Air suction
Liquid pipe
Gas pipe
Drain pipe
Right side piping/wiring connection
Left side piping/wiring connection
Ø6.35 Flare connection Ø12.7 Flare connection External dia. Ø17
PIPE AND DRAIN DIMENSION
PIPING/WIRING
DIRECTION
PIPING/WIRING DIRECTION
PIPING DIRECTION
Lower than 2.3m More than 200 mm
Higher than eye-level
More than 100 mm
More than 100 mm
Name
1 2 3 4 5 6 7 8
Number
※ Required space(unit:mm)
Descripition
(unit : mm)
