LG multi V ARUM Series Installation Manual

Installation Manual 15
ENGLISH
Installation Space
Inspection door(NOTICE 1)
(servicing space)
481
345
100 more
100 more
(Serviceing space)
(Serviceing space)
300more
(Servicing space)
300more
(Servicing space)
300more
(Servicing space)
450more
(Servicing space)
1
2
3
54
6
7
453(174)
(174)
182
218
41961 (137)
124
128
30 60
(NOTICE 2)
(NOTICE 2)
450
450
100 more
(Serviceing space)
100 more
100 more
(Serviceing space)
(Serviceing space)
100 more
(Serviceing space)
Description
PRHR040/030 PRHR020
1 Low pressure Gas pipe connection port Ø28.58 Brazing connection Ø22.2 Brazing connection
2 High pressure Gas pipe connection port Ø22.2 Brazing connection Ø19.05 Brazing connection
3 Liquid pipe connection port Ø12.7 Brazing connection Ø9.52 Brazing connection
4 Indoor unit Gas pipe connection port Ø15.88 Brazing connection Ø15.88 Brazing connection
5 Indoor unit Liquid pipe connection port Ø9.52 Brazing connection Ø9.52 Brazing connection
6 Control box
7 Hanger metal M10 of M8 M10 of M8
Part NameNo.
:
1. Be sure to install the inspection door at the control box side.
2. If reducers are used, servicing space must be increased equal to reducer's dimension.
NOTICE
