Refrigerant piping installation
When connecting the pipes from the front of
the outdoor unit, Remove part
(or part
and part ).
When connecting the pipes from the side of the
outdoor unit, remove part (the whole "Knock
out" part).
Knock out
Transmission Line Hole
Power Cable Hole
Pipe Hole
(Front) (Side)
3
WARNING
After installing the pipe, clog the pipe excavation inlet of the front panel and the side panel
(Wire may be damaged due to entering of rats, animals, etc).
