LG multi V ARUM Series Installation Manual

44 Outdoor Unit
Electrical Wiring
Main Sub1 Sub2
Main Sub1 Sub2
Main Sub1 Sub2
Main Sub1 Sub2
Remote
control
Remote
control
Indoor
unit
Indoor
unit
Outdoor units
Outdoor units
Outdoor units
Outdoor units
Remote
control
Remote
control
Indoor
unit
Indoor
unit
Remote
control
Remote
control
Indoor
unit
Indoor
unit
HR
unit
HR
unit
HR
unit
2-core shield cable Multi-core cable
HR
unit
Remote
control
Remote
control
Indoor
unit
Indoor
unit
CAUTION
• Use the 2-core shield cables for transmission lines. Never use them together with power cables.
• Never use multi-core cable
• As this unit is equipped with an inverter, to install a phase leading capacitor not only will deteriorate
power factor improvement effect, but also may cause capacitor abnormal heating. Therefore, never
install a phase leading capacitor.
• Keep power imbalance within 2% of the supply rating. Large imbalance will shorten the life of the
smoothing capacitor.
