Electrical Wiring
◆ Wiring of Main Power Supply and Equipment Capacity
Outdoor unit (3Ø, 380 ~415V, 50Hz ) Indoor unit (1Ø, 220V, 50Hz)
1. Use a separate power supply for the outdoor unit and indoor unit.
2. Bear in mind ambient conditions (ambient temperature,direct sunlight, rain water,etc.) when proceeding with the wiring and connections.
3. The wire size is the minimum value for metal conduit wiring. The power cord size should be 1 rank thicker taking into account the line volt-
age drops. Make sure the power-supply voltage does not drop more than 10%.
4. Specific wiring requirements should adhere to the wiring regulations of the region.
5. Power supply cords of parts of appliances for outdoor use should not be lighter than polychloroprene sheathed flexible cord.
6. Don't install an individual switch or electrical outlet to disconnect each of indoor unit separately from the power supply.
WARNING
• Follow ordinance of your governmental organization for technical standard related to electrical equipment, wiring reg-
ulations and guidance of each electric power company.
• Be sure to use specified wires for connections so that no external force is imparted to terminal connections. If connec-
tions are not fixed firmly, it may cause heating or fire.
• Be sure to use the appropriate type of overcurrent protection switch. Note that generated overcurrent may include
some amount of direct current.
CAUTION
•
Some installation site may require attachment of an earth leakage breaker. If no earth leakage breaker is installed, it may
cause an electric shock.
• Do not use anything other than breaker and fuse with correct capacity. Using fuse and wire or copper wire with too large
capacity may cause a malfunction of unit or fire.
Unit
Model
Power Supply COMP OFM
Hz Volts
Voltage-range
MCA MOP MSC RLA kW FLA
8HP 50 380-415 20.7 34.1 16.5/75 14.5/12 0.56 3.97
10HP 50 380-415 26.5 44.5 16.5/75 14.5/12 0.56 3.97
12HP 50 380-415 27.2 45.8 16.5/75 14.5/12 0.56 3.97
14HP 50 380-415 30.5 51.7 16.5/75 14.5/12 0.56 3.97
16HP 50 380-415 41.2 68.0 16.5/75/75/75 14.5/12/12/12 1.1 7.71
18HP 50 380-415 47.0 78.4 16.5/75/75/75 14.5/12/12/12 1.1 7.71
20HP 50 380-415 52.7 88.7 16.5/75/75/75 14.5/12/12/12 1.1 7.71
22HP 50 380-415 53.5 90.1 16.5/75/75/75 14.5/12/12/12 1.1 7.71
24HP 50 380-415 54.2 91.4 16.5/75/75/75 14.5/12/12/12 1.1 7.71
26HP 50 380-415 67.5 112.3 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
28HP 50 380-415 73.2 122.6 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
30HP 50 380-415 79.0 133.0 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
32HP 50 380-415 79.7 134.3 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
34HP 50 380-415 80.5 135.7 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
36HP 50 380-415 81.2 137.0 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
38HP 50 380-415 84.5 142.9 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
40HP 50 380-415 87.7 148.7 16.5/75/75/75/75/75 14.5/12/12/12/12/12 1.64 11.45
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
Min.:342
Max.:456
