LG Multi V ARUN053GF2 - General Data and Specifications; Unit Specifications; Electrical Data

7
Product Data
Due to our policy of continuous product innovation, some specifications may change without notification.
©LG Electronics U.S.A., Inc., Englewood Cliffs, NJ. All rights reserved. “LG” is a registered trademark of LG Corp.
Unit Model Number
4.4 Ton
ARUN053GF2
Cooling Performance
Nominal Cooling Capacity (Btu/h)
1
53,000
Rated Cooling Capacity (Btu/h)
2
54,000
Heating Performance
Nominal Heating Capacity (Btu/h)
1
59,000
Rated Heating Capacity (Btu/h)
2
60,000
Operating Range
Cooling (°F DB) 23 - 118
Heating (°F WB) (-4) - +60
Compressor
Inverter Quantity Inverter
Oil/Type PVE/FVC68D
Fan (Rear Discharge)
Type Propeller (BLDC)
Motor Output (kW) x Qty. 0.90 x 1
Motor/Drive Brushless Digitally Controlled/Direct
Operating Range (RPM)
Cooling 80-813
Heating 80-813
Maximum Air Volume (CFM) 3,532
External Static Pressure Fan (inches WG) 0.12 - 0.20
Unit Data
Refrigerant Type R410A
Refrigerant Control/Location EEV/Indoor Unit
Max. Number Indoor Units/System
3
9
Sound Pressure dB(A) (Rear Fan Side/Front)
4
53 / 68
Net Unit Weight (lbs.) 320
Shipping Weight (lbs.) 346
Communication Cables
5,6
2 x 18
Heat Exchanger
Material and Fin Coating Copper Tube/Aluminum Fin and GoldFin™
Rows/Fins per inch 2/14
Piping
7
Liquid Line Connection (in., OD) 3/8 Braze
Vapor Line Connection (in., OD) 3/4 Braze
Factory Charge lbs. of R410A 7.7
Table 1: Single-Frame 208-230V Heat Pump Unit Specications.
1
Nominal capacity applied with non-ducted indoor units, and is rated 0 ft. above sea level with 25 ft.
of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor units. All
capacities are net with a Combination Ratio between 95–105%. (Nominal capacity is outside the scope
of AHRI Standard 210/240.)
Nominal cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF
wet bulb (WB) and outdoor ambient conditions of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Nominal heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and
59ºF wet bulb (WB) and outdoor ambient conditions of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
2
Rated capacity is certified under AHRI Standard 210/240. See www.ahrinet.org for information.
3
The System Combination Ratio must be between 50–130%.
4
Sound pressure levels are tested in an anechoic chamber under ISO Standard 3745
5
All communication cable to be minimum 18 AWG, 2-conductor, stranded, shielded, and must comply
with applicable local and national codes.
6
Power wiring cable is field provided and must comply with the applicable local and national codes. See
below for detailed electrical data.
7
Refer to the Refrigerant Piping section of this manual for correct line sizing. Contractor must use LG
manufactured Y-Branch and Header Kits only. Designer must verify refrigerant piping design configura-
tion using LG’s computerized refrigerant piping (LATS Multi V) software to validate the pipe design.
Nominal Tons Unit Model No. Compressor Qty. Compressor Motor (A) Fan Qty. Condenser Fan Motor (A) MCA MOP
4.4 ARUN053GF2 1 21.7 1 4.0 31.2 50
Table 2: Multi V Space II Electrical Data
Voltage tolerance is ±10%.
Maximum allowable voltage unbalance is 2%.
MCA = Minimum Circuit Ampacity.
Maximum Overcurrent Protection (MOP) is calculated as follows: (Largest motor FLA x 2.25) + (Sum of
other motor FLA) rounded down to the nearest standard fuse size.
GENERAL DATA
Space II Unit Specications / Electrical Data
