INSTALLATION SPACE
ENGLISH
INSTALLATION SPACE
• The following values are the least space for installation. If any service area is needed for service
according to field circumstance, obtain enough service space.
• The unit of values is mm.
In case of obstacles on the suction side
1. Stand alone installation
2. Collective installation
500 or less
more
1,000 or
c
a
100 or
more
100 or
more
500 or less
more
1,000 or
150 or
more
150 or
more
c
b
100 or
more
200 or
more
1,000 or
more
c
500 or less
more
1,000 or
100 or
more
1,000 or
more
200 or
more
c
[Unit:mm]
8HP 10Hp/12HP
a 100 or more 200 or more
b 100 or more 300 or more
c 300 or more 350 or more
