OUTDOOR UNITS INFORMATION
9
ENGLISH
Power Supply : 3 Ø, 220-240 V3, 50 Hz
3 Ø, 220 V3, 60Hz
CAUTION
• Ratio of the connectable Indoor Units to the Outdoor: Within 50 ~ 160%
• Ratio of running Indoor Units to the Outdoor: Within 10 ~ 100%
• A combination operation over 100% cause to reduce each indoor unit capacity.
!
OUTDOOR UNITS INFORMATION
System(HP) 8 10 12
Model ARUN080BSR0 ARUN100BSR0 ARUN120BSR0
Refrigerant Precharged
Amount
kg 3.5 4.5 6
lbs 7.7 9.9 13.2
Net weight
kg 115 144 157
lbs 253 317 346
Dimensions (WxHxD)
mm 950 x 1,380 x330 1,090 x 1,625 x 380 1,090 x 1,625 x 380
inch 37.4 x 54.3 x 13.0 42.9 x 64.0 x 15.0 42.9 x 64.0 x 15.0
Piping
Connections
Liquid Pipes mm(inch) Ø9.52(3/8) Ø9.52(3/8) Ø12.7(1/2)
Gas Pipes mm(inch) Ø19.05(3/4) Ø22.2(7/8) Ø28.58(11/8)
1,MFL67798027,영영 2018. 6. 18. 영영 3:07 Page 9
