LG multi V ARUN080BSR0 User Manual

ELECTRICAL WIRING
55
ENGLISH
Example) Connection of power and communication cable
12/10 HP
8HP
Insulation sleeves
attachment
Power/
Ground cable
Power/
Ground cable
Communication
cable
Over 50mm gap
Main power
Terminal block
Ground wire
Fix firmly not to be
displaced
ODU-IDU
Communication cable
Hold power cable
Hold
communication
cable
Insulation sleeves
attachment
Power/
Ground cable
Power/
Ground cable
View A
A
Communication
cable
Over 50mm gap
Fix firmly not to be
displaced
ODU-IDU
Communication cable
Hold power cable
Communication
cable
Main power
Terminal block
Hold Communication
cable
Ground wire
Fix firmly
not to be
displaced
Over
50mm gap
Power/
Ground cable
Communication
cable
Over
50mm gap
Power/
Ground cable
Communication
cable
Right side Front side
Right side Front side
※Pictures may differ depending on the model.
1,MFL67798027,영영 2018. 6. 18. 영영 3:07 Page 55
