n Checking according to dip switch setting
1. You can check the setting values of the Master Compressor Module from the 7 segment LED.
The dip switch setting should be changed when the power is OFF.
2. It checks whether the input is properly performed without the bad contact of the dip switch or not
n Checking the setting of Compressor Module
Checking according to dip switch setting
- You can check the setting values of the Master Compressor Module from the 7 segment LED.
The dip switch setting should be changed when the power is OFF.
Checking the initial display
The number is sequentially appeared at the 7 segment in 5 seconds after applying the power. This number represents the
setting condition. (For example, represents R410A 5HP)
Checking the setting of MULTI V M
• Initial display order
Order No Note
①
5~8 Model capacity
②
1 Cooling only
2 Heat pump
③
38 380V
46 460V
22 220V
④
1 Standard
5 Cold temperature area
6 Tropical
Test Run
