Installation Space
12 Outside Unit
Installation Space
• The following values are the least space for installation.
If any service area is needed for service according to field circumstance, obtain enough service space.
• The unit of values is mm.
n In case of obstacles on the suction side
1. Stand alone installation
2. Collective installation
100(3-15/16)
or more
100(3-15/16)
or more
100(3-15/16)
or more
100(3-15/16)
or more
1000 (39-1/4)
or more
100(3-15/16)
or more
500(19-5/8)
or less
500(19-5/8)
or less
500(19-5/8)
or less
1000 (39-1/4)
or more
1000 (39-1/4)
or more
150(3-15/16)
or more
150(3-15/16)
or more
150(3-15/16)
or more
100(3-10/11)
or more
100(3-15/16)
or more
200(7-7/8)
or more
200(7-7/8)
or more
1000 (39-1/4)
or more
1000 (39-1/4)
or more
300(11-7/8)
or more
300(11-7/8)
or more
Unit:mm(inch)
Unit:mm(inch)
