30 Outdoor Unit
Common pipe Liquid pipe Gas pipe
Remove only liquid/gas pipe Knock Out View without base pan
Common pipe
View without base pan
Liquid pipe Gas pipe
n Method of drawing out pipes on the bottom side
Drawing out common pipe through side panel
n Figure of Sides when drawing out through bottom pipe
Drawing out common pipe through bottom pipe
Remove Pipe
Knock Out Hole
i) Single outdoor unit
ii) Series outdoor units
(Draw out common pipes
through bottom)
iii) Series outdoor units
(Draw out common pipes
through side panel)
Pipe connections between indoor and outdoor unit
