LG MW122C4 User Manual

8
EN
INSTALLATION DIAGRAM
Distance from ceiling
should be over 200 mm
Distance from the wall
should be over 50 mm
Distance from the obstacle
should be over 3000 mm
Distance from floor
should be over 2500 mm
Distance from the obstacle
should be over 500 mm
Air intake distance
from the wall should
be over 250 mm
Air intake distance
from the wall should
be over 250 mm
Air intake distance from the
wall should be over 500 mm
Distance from the wall
should be over 50 mm
over 250 mm
WARNING
• Installation must be performed in accordance with the national wiring standards by authorized personnel only.
NOTE
• Above figure is only a simple presentation of the unit, it may not match the external appearance of the unit you
purchased.
