Connecting 11
Connecting
2
3. Remove the Wall Mount Bracket Installation
Template.
4. Fix it with screws (not supplied) as shown in the
illustration below.
5. Hang the main unit onto the bracket as shown
below.
y
Do not hang onto the installed unit and
avoid any impact to the unit.
y
Secure the unit rmly to the wall so that it
does not fall o. If the unit falls o, it may
result in an injury or damage to the product.
y
When the unit is installed on a wall, please
make sure that a child does not pull any of
connecting cables, as it may cause it to fall.
>
Caution
Detach the unit from the bracket as shown
below.
,
Note
Optional Equipment
Connection
OPTICAL In connection
Connect an optical output of external devices to
the OPTICAL IN connector.
To the digital
optical output
jack of external
device
NB2020A-NB_DUSALLC.indd 11 2012-06-28 �� 3:19:48
