Appendix 33
Appendix
4
Specifications
General
Power requirements Refer to main label on the rear panel.
Power consumption Refer to main label on the rear panel.
Dimensions (W x H x D) (245 X 245 X 245) mm
Net Weight (Approx.) 6 kg
Operating temperature 5 °C to 35 °C (41 °F to 95 °F)
Operating humidity 5 % to 90 %
USB 5 V
0
500 mA
iPod/iPhone/iPad 5 V
0
2.1 A
Inputs
PORT. IN 0.5 Vrms (3.5 mm stereo jack)
Tuner
FM Tuning Range 87.5 MHz to 108.0 MHz or 87.50 MHz to 108.00 MHz
Amplier
Output Power 20 W X 2 ch + 40 W (8 Ω + 4 Ω at 1 kHz)
T.H.D 10 %
Speakers
Type built-in
Impedance Rated 8 Ω + 4 Ω
Rated Input Power 20 W + 40 W
Max Input Power 40 W + 80 W
Wireless
Wireless LAN 802.11 b/g
y
Design and specications are subject to change without notice.
