CIRCUIT VOLTAGE CHART
1. ICs
3-67 3-68
Parts Name
Specifi cation Ratied -20% Ratied +20%
Voltage (V) Voltage (V) Voltage (V)
IC101
MICOM
R5F100GEAFB VDD:-0.5~6.5V VDD : 3.31V VDD : 3.31V
IC102
Voltage Detector
AZ7027RTRE1 VCC: Max 18V
Vcc : 3.37V
Vout : 3.36V
Vcc : 3.37V
Vout : 3.36V
IC103
Voltage Detector
AZ7027RTRE1 VCC: Max 18V
Vcc : 3.37V
Vout : 3.36V
Vcc : 3.37V
Vout : 3.36V
IC201
A/D Converter
CS5346
VA : 4.75~5.25V
VD : 3.13~3.47V
VLS : 3.13~5.25V
VLC : 3.13~5.25V
VA : 5.01V
VD : 3.32V
VLS : 3.32V
VLC : 3.32V
VA : 5.01V
VD : 3.32V
VLS : 3.32V
VLC : 3.32V
IC202
PWM
PS9860
AVDD, AVDD_PWM,
DVDD_CORE
: 0~3.6V
AVDD,
AVDD_PWM,
DVDD_CORE
: 3.23V
AVDD,
AVDD_PWM,
DVDD_CORE
: 3.23V
IC203~5,IC802
OP Amplifi er
AZ4580MTR-E1 VCC: ~20V VCC: 5.02V VCC: 5.02V
IC206
A/D Converter
PCM1808
VCC : -0.3~6.5V
VDD : -0.3~4V
VCC : 5.00V
VDD : 3.32V
VCC : 5.00V
VDD : 3.32V
IC207,IC601
LDO Voltage Requlator
LM37102D-ADJ
Vin : 2.25~16V
Vout : 1.25~15V
Vin : 5.63V
Vout : 5.20V
Vin : 5.63V
Vout : 5.20V
IC400
Motor Driver
AM5890 VCC : 4.3~13.2V VCC : 8.74V VCC : 8.74V
IC401
RF, Servo
BU9546KV
DVDD,AVDD : 2.7~3.6V
VDD_CORE :
1.75~1.95V
DVDD,AVDD : 3.26V
VDD_CORE : 1.85V
DVDD,AVDD : 3.25V
VDD_CORE : 1.85V
IC402
DC/DC Converter
TPS54331D
VIN : -0.3~20V
VRGE : -0.5~6.5V
VIN: 11.83V
VOUT: 5.50V
VIN: 11.83V
VOUT: 5.50V
IC501
DSP
MLC3730S
VDD12 : 1.08~1.32V
VDD33 : 3.0~3.6V
VDD12 : 1.2V
VDD33 : 3.36V
VDD12 : 1.2V
VDD33 : 3.36V
IC502
SDRAM
W9825G6KH-6 256MBIT VDD,VDDQ : 3.0~3.6V VDD,VDDQ : 3.36V VDD,VDDQ : 3.36V
IC503
Serial Flash Memory
W25Q128FVSIG
128MBIT
Vcc : 2.7~3.6V Vcc : 3.37V Vcc : 3.37V
IC504
Serial Flash Memory
W25Q80DVSSIG 8MBIT Vcc : 2.7~3.6V Vcc : 3.37V Vcc : 3.37V
IC505
LDO Voltage Requlator
TJ4220GDP-ADJ
Vin : 2.5~6.5V
Vout : 2.5~5V
Vin : 4.90V
Vout : 3.33 V
Vin : 4.91V
Vout : 3.33 V
IC507,IC508
Voltage Regulator
AZ1117BH-ADJTRE1
Vin : Max 12V
Vout : Max 10V
Vin : 5.12V
Vout : 3.36V
Vin : 5.12V
Vout : 3.36V
IC600
DC/DC Converter
TPS54331D VIN : 3.5~28V VIN: 12.67V VIN: 12.67V
IC602
D/A Converter
PCM5101APWR
CPVDD/AVDD/DVDD :
3.0~3.6V
CPVDD/AVDD/DVDD :
3.32V
CPVDD/AVDD/DVDD :
3.32V
IC603
Clock Driver
BU2090 Vin : 2.7~5.5V Vin : 3.37V Vin : 3.37V
IC700~IC705
Power Driver
IRS2092
VB : 0~220V
VAA : MAX 210V
VB : 11.32V
VAA : 5.12V
VB : 11.33V
VAA : 5.12V
ICA301
PRE Amplifi er
DRV632 VCC: -0.3~4.0V VCC:3.32V VCC:3.32V
2. CAPACITORS
Location No. Capacity Specifi cation
Rated-20%(88V, 60Hz) Rated+20%(288V, 60Hz)
Voltage (V) Voltage (V)
C209 4.7u 50V 2.02 2.02
C226 100u 16V 11.31 11.32
C231 100u 16V 5.00 5.00
C238 220u 16V 3.30 3.30
C240 220u 6.3V 1.26 1.26
C308 47u 16V 5.21 5.21
C344 47u 16V 5.01 5.01
C345 47u 16V 5.64 5.64
C347 470u 10V 3.37 3.38
C402 100u 16V 5.00 5.00
C404 47u 16V 3.32 3.32
C409 47u 16V 3.32 3.32
C416 47u 16V 1.66 1.66
C418 3.3u 50V 0.52 0.51
C427 220u 16V 8.73 8.73
C501 220u 10V 3.23 3.23
C5C9 1000u 6.3V 3.35 3.36
C5E1 47u 16V 3.36 3.35
C604 47u 16V 5.12 5.12
C622 470u 16V 2.77 2.77
C627 47u 50V 27.04 27.09
C707 1000u 80V 65.84 65.84
C728 1000u 80V 65.56 65.58
C752 2200u 80V 65.98 65.98
C798 2200u 16V 66.08 66.08
C904 330u 450V 394.50 394.50
C926 47u 50V 15.72 15.74
C927 47u 50V 17.10 17.20
C936 1000u 16V 5.65 5.65
C937 2200u 16V 5.66 5.66
C944 470u 25V 12.64 12.70
C948 220u 25V 7.00 6.92
C958 100u 16V 11.83 11.84
C963 1000u 25V 16.17 16.18
C964 220u 25V 11.81 12.02
C966 1000u 80V 66.10 66.07
C968 1000u 80V 65.58 65.84
