EXTERNAL CONTROL DEVICE SETUP
Communication Parameters
Baud rate: 9600 bps (UART)
Data length: 8 bits
Parity : None
Stop bit: 1 bit
Communication code: ASCII code
Use a crossed (reverse) cable.
Command reference list
COMMAND1 COMMAND2
DATA
(Hexadecimal)
COMMAND1 COMMAND2
DATA
(Hexadecimal)
01. Power k a 00 - 01 14. Treble k r 00 - 64
02. Input Select x b (See p.98) 15. Bass k s 00 - 64
03. Aspect
Ratio
k c (See p.98) 16. Balance k t 00 - 64
04. Screen
Mute
k d 00 - 01
17. Color
Temperature
x u 00 - 64
05. Volume
Mute
k e 00 - 01
18. ISM
Method
j p (See p.99)
06. Volume
Control
k f 00 - 64
19. Energy
Saving
j q (See p.99)
07. Contrast k g 00 - 64
20. Auto
Configuration
j u (See p.99)
08. Brightness k h 00 - 64
22. Channel
Add/Del
m b 00 - 01
09. Color k i 00 - 64 23. Key m c (See p.100)
10. Tint k j 00 - 64
11. Sharpness k k 00 - 32
12. OSD Select k l 00 - 01
13. Remote
Control
Lock Mode
k m 00 - 01
COMMAND1 COMMAND2
DATA00
(Hexadecimal)
DATA01
(Hexadecimal)
DATA02
(Hexadecimal)
DATA03
(Hexadecimal)
DATA04
(Hexadecimal)
DATA05
(Hexadecimal)
21. Channel
Tuning
m a
physical
program
high
major
program
low
major low minor high minor low attribute
