ASSEMBLING AND PREPARING
NOTE

The items supplied with your product may vary depending on the model.

Product specifications or contents of this manual may be changed without prior notice due to
upgrade of product functions.

How to use the ferrite core
1 Use the ferrite core to reduce the electromagnetic interference in the PC audio cable.
Wind the PC audio cable on the ferrite core thrice. Place the ferrite core close to the TV.
[to an External device] [to the TV]
2 Use the ferrite core to reduce the electromagnetic interference in the power cable.
Wind the power cable on the ferrite core once. Place the ferrite core close to the TV and a wall
plug.
[to a wall plug] [to the TV]
3 Use the ferrite core to reduce the electromagnetic interference in the component cable.
Wind the component cable on the ferrite core once. Place the ferrite core close to the TV.
[to an External device] [to the TV]
4 Use the ferrite core to reduce the electromagnetic interference in the component cable.
Place the ferrite core close to the TV.
[to an External device] [to the TV]
- If there are three ferrite cores, follow as shown in Figures 1 and 2.
- If there are four ferrite cores, follow as shown in Figures 1, 2, 3 and 4.
(FOR PA4900 SERIES)
Use the ferrite core to reduce the electromagnetic interference in the charging cable.
Wind the charging cable on the ferrite core once. Place the ferrite core close to an external device
and the cradle or touch pen.
[to an External device] [to the cradle or touch pen]
(Gray)
[Cross Section of
Ferrite Core]
(Gray)
[Cross Section of
Ferrite Core]
(Black)
[Cross Section of
Ferrite Core]
(Black)
[Cross Section of
Ferrite Core]
(Black)
[Cross Section of
Ferrite Core]
[Figure 1]
[Figure 2]
[Figure 3]
[Figure 4]
[Figure 5]
10 mm(+ / - 5 mm)
10 mm(+ / - 5 mm)
10 mm(+ / - 5 mm)
