LG PB60G Service Manual

North/Latin America http://aic.lgservice.com
Europe/Africa http://eic.lgservice.com
Asia/Oceania http://biz.lgservice.com
Internal Use Only
Printed in KoreaP/NO : MFL67479903 (1209-REV01)
DLP PROJECTOR
SERVICE MANUAL
CHASSIS : FM21B
MODEL : PB60G PB60G-JE
CAUTION
BEFORE SERVICING THE CHASSIS,
READ THE SAFETY PRECAUTIONS IN THIS MANUAL.

LG PB60G Specifications

General

Native aspect ratio	16:9
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	15000:1
Digital gamma correction	Yes
Screen size compatibility	25 - 100 \
Projector native resolution	WXGA (1280x800)
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	30000 h
Focus	Manual
Offset	100 %
Throw ratio	1.5:1
Focal length range	- mm
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Analog signal format system	-
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 800 (WXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 854 x 480 (WVGA)
RMS rated power	2 W
Number of built-in speakers	2
Audio (L/R) in	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Noise level	31 dB
Certification	KC/KCC, FCC/UL
Noise level (economic mode)	26 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, ITA, KOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Tripod
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (standby)	0.5 W
Cables included	AC, Component
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	103 mm
Width	158 mm
Height	33 mm
Weight	470 g
