LG PB60G Service Manual

- 4 -
LGE Internal Use OnlyCopyright © LG Electronics. Inc. All rights reserved.
Only for training and service purposes
SPECIFICATION
NOTE : Specifications and others are subject to change without notice for improvement .
1. Application range
This spec sheet is applied all of the DLP Projector with FM21B chassis.
2. Requirement for Test
Each part is tested as below without special appointment.
(1) Temperature: 25 °C ± 5 °C(77 °F ± 9 °F), CST: 40 °C ± 5 °C
(2) Relative Humidity: 65 % ± 10 %
(3) Power Voltage
: Standard input voltage (AC 100-240 V~, 50/60 Hz)
* Standard Voltage of each products is marked by models.
(4) Specification and performance of each parts are followed each drawing and specification by part number in accordance with
BOM.
(5) The receiver must be operated for about 5 minutes prior to the adjustment.
3. Test method
(1) Performance: LGE TV test method followed
(2) Demanded other specification
Safety : UL, CSA, IEC, CE specification (EN55022 Class B)
EMC : FCC, ICES, IEC, CE specification (EN60950-1)
4. Model General Specification
No Item Specication Remark
Min Max Unit
1 Video input applicable system 1) NTSC M
2) PAL-B,D,G,H,I
3) PAL M
4) PAL N
5) PAL 60
6) SECAM
3.579545 / 60 Hz
4.433618 / 50 Hz
3.575611 / 60 Hz
3.582056 / 50 Hz
4.433618 / 60Hz
2 Power Adapter - DC 19.5V @ 4.62A (90W)
3 Input Voltage AC 100 ~ 240(± 10 %)V, 50/ 60Hz
4 Market Global
5 Picture size WXGA (1280 x 800)
6 Aspect ratio 16:10 Panel Resolution
7 Operating Temperature 0 40 deg
8 Operating Humidity 80 %
9 Storage Temperature -20 60 deg
10 Storage Humidity 85 %

LG PB60G Specifications

General

Native aspect ratio	16:9
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	15000:1
Digital gamma correction	Yes
Screen size compatibility	25 - 100 \
Projector native resolution	WXGA (1280x800)
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	30000 h
Focus	Manual
Offset	100 %
Throw ratio	1.5:1
Focal length range	- mm
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Analog signal format system	-
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 800 (WXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 854 x 480 (WVGA)
RMS rated power	2 W
Number of built-in speakers	2
Audio (L/R) in	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Noise level	31 dB
Certification	KC/KCC, FCC/UL
Noise level (economic mode)	26 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, ITA, KOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Tripod
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (standby)	0.5 W
Cables included	AC, Component
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	103 mm
Width	158 mm
Height	33 mm
Weight	470 g
