LG PB60G Service Manual

1.PB61K,PB60G Features
Projection System General Specification
Korean / English / French/ Spanish/ German / Italian / Swedish /
DLP/045inchDMD
Display Technology
Korean
/
English
/
French/
Spanish/
German
/
Italian
/
Swedish
/
Portuguese / Chinese Simplified / polish/ Brazilian Portuguese/
Russian/Greek / Arabic/ Turkish/ Taiwanese
Russia / Brazil / Arabic
Aspect Ratio Control
Sound
DLP
/
0
.
45
inch
DMD
WXGA (1280X800)
500
15000:1
34dB
(Hi h B i ht )
Display
Technology
Native Resolution)
Brightness (ANSI-Lumens)
Contrast Ratio
Ni
16:10 / 4:3
2 x 1W speaker
Sound
Dimension (mm)
Weight (kg)
Power Consumption
34dB
(Hi
g
h
B
r
i
g
ht
ness
)
31dB (Normal)
25dB (Economic)
>85%
N
o
i
se
Uniformity
2
x
1W
speaker
158x103x33 mm
450g
65W / Stand-by 0.5W under
Terminals
Manual Focus
Fixed Zoom
Screen Size 25~100”
Standard 40˚@1.29m
Projection Lens
Projection Image
1*HDMI (ver 1.3)
1*RGB in
1*Composite
1*USB (DivX)
1*Audio in
*
Throw Ratio 1.5
R/G/B LED
Life 30,000Hrs
Lamp
1
*
Audio out
Embedded Divx (MP3, JPEG, MPEG4)
Wide Digital Keystone Correction
Special Features
Picture Still (PB60G)
Quick Power on/off,
Auto Off
Auto Power
Expert Color Control
Copyright © 2012 LG Electronics Inc. All rights reserved.
Only for training and service purposes
LGE Internal Use Only

LG PB60G Specifications

General

Native aspect ratio	16:9
Projection distance	- m
Projection technology	DLP
Supported aspect ratios	4:3, 16:9
Contrast ratio (typical)	15000:1
Digital gamma correction	Yes
Screen size compatibility	25 - 100 \
Projector native resolution	WXGA (1280x800)
Lamps quantity	1 lamp(s)
Light source type	LED
Service life of light source	30000 h
Focus	Manual
Offset	100 %
Throw ratio	1.5:1
Focal length range	- mm
Full HD	No
Supported video modes	1080i, 1080p, 480i, 480p, 720p
Analog signal format system	-
Supported graphics resolutions	1280 x 720 (HD 720), 1280 x 800 (WXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 854 x 480 (WVGA)
RMS rated power	2 W
Number of built-in speakers	2
Audio (L/R) in	3
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
S-Video inputs quantity	0
Noise level	31 dB
Certification	KC/KCC, FCC/UL
Noise level (economic mode)	26 dB
On Screen Display (OSD) languages	ARA, CHI (SIMPL), DEU, ENG, ESP, FRE, GRE, ITA, KOR, POL, POR, RUS, SWE, TUR
Placement	Desktop, Tripod
Product type	Standard throw projector
Product color	White
Cable lock slot type	Kensington
Power source	AC
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	60 W
Power consumption (standby)	0.5 W
Cables included	AC, Component
Operating temperature (T-T)	0 - 40 °C

Weight and Dimensions

Depth	103 mm
Width	158 mm
Height	33 mm
Weight	470 g
