Discharging
Duct
Outdoor
unit
If ducting is installed, fan external static pressure can be increased
- Enhanced installation flexibility (doesn’t just have to be installed against a louvered wall).
- No need to change the fan motor (jumper settings made on the main PCB).
- No capacity reduction, or increase in noise levels.
Duct application
LG patent for
All technologies in the which make it a distinctive, unique unit has been
applied for patents domestically and internationally. And, some of them have already been registered.
Outdoor unit
LG patents : 57 items
• Housing
(in main PCB)
• Connector
(in the bag with installation manual)
Insert connector
as manual
1)
2)
3)
4)
5)
6)
10HP 5HP
0~3 0~2
3~6 2~3
6~8 3~4
8~10 4~5
10~12 5~6
12~14 6~7
connector
connector
connector
connector connector
connectorconnector
Air handler structrue (18)
Separation of suction & discharge (6)
3-side heat exchange structure (3)
Louver structure / control (20)
Electrical part (2)
Whole structure (8)
How to set up E.S.P (unit : mmAq)
Air conditioning system _49
