12
BEFORE USING
e
Mop Holder
f
Mop Pad
g
Floor Damage Prevention Plate
• The robot vacuum cleaner may fall if there is a
cliff or drop that is less than 10cm. In this case,
you can prevent this by purchasing and installing
the Roboking magnetic strip (sold separately).
Specifications
This product is a Class I laser device of which
conformity assessment is conducted in accordance
with the IEC 60825-1.
Robot Cleaner
•
Model
: R3-PRIME
•
Maximum Physical Dimensions
: 355 mm
(Width) × 355 mm (Depth) × 83 mm (Height)
•
Power Consumption
- 25 W (standard level)
•
Charging Time
: Approximately 4-5 hours
•
Cleaning Time (Based on general wooden
floor)
- Up to 90 minutes (standard level)
Home Station
•
Input
: 100-240 V~, 50/60 Hz, 0.4 A
•
Output
: DC 19 V, 0.6 A
Charging
Installing the Home Station
Always keep the home station plugged in when in
use. If the home station is not plugged in, the robot
cleaner will not return to the home station to
charge automatically.
1
Before using for the robot cleaner for the first
time, remove the foam strips located behind
the collision bumper.
2
Open the cover at the bottom of the charging
stand, connect the adapter to the charging
stand, and wrap the power cord around the
power cord organizer as shown in the picture.
Assemble the cover at the bottom of the
removed charging base until you hear a “click”
sound.
3
Install the charging dock onto the floor
damage prevention plate. When installing the
charging dock, first slide the charging dock
into the groove on the front of the damage
prevention plate and then press to install it.
4
Place the charging dock on a level surface,
keep the surrounding area open, and place it
against the wall.
global_main.book.book Page 12 Monday, July 10, 2023 3:22 PM
