LG RK8 User Manual

Connecting
14
Connecting
2
Optional Equipment
Connection
PORT. IN Connection
Connect an output (earphone or line out) of portable
device (MP3 or PMP etc) to the PORT. IN
(3.5 mm) connector.
.
Portable cable
MP3 player etc.
Listening to music from your
portable player
The unit can be used to play music from many types
of portable player or external device.
1. Connect the portable player to the PORT. IN
connector of the unit.
2. Turn the power on by pressing
1
.
3. Press F to select PORTABLE function.
4. Turn on the portable player and start it playing.
Automatically switches to the PORTABLE
function when you connect the portable device
to the PORT. IN connector.
,
Note
USB Connection
Connect a USB device (or MP3 player, etc.) to the
USB ports on the unit.
USB device
Removing the USB device from the unit :
1. Choose a different function.
2. Remove the USB device from the unit.
,
Note

LG RK8 Specifications

General

Tweeter	Yes
Speaker type	2-way
Woofer diameter	101.6 mm
Tweeter diameter	50.8 mm
Number of drivers	4
Number of speakers	1
Audio output channels	- channels
Recording on	USB
Recommended usage	Universal
Card reader integrated	-
Audio formats supported	MP3, WMA
Coloration	Monochromatic
Battery life (max)	10 h
Power source	AC/Battery
Power source type	Battery
Power consumption (standby)	0.5 W
Power consumption (typical)	58 W
Headphone connectivity	3.5 mm
USB 2.0 ports quantity	2
Connectivity technology	Wired & Wireless
RMS rated power	100 W
Product color	Black
Volume control	Rotary
Equalizer modes	Bass, Classic, Custom, Jazz, Pop, Rock
FM band range	87.5 - 108 MHz
Supported radio bands	FM

Weight and Dimensions

Depth	206 mm
Width	455 mm
Height	241 mm
Weight	9888 g
Package depth	277 mm
Package width	531 mm
Package height	363 mm
Package weight	11385 g
