1-17
Copyright © 2017 LG Electronics Inc. All rights reserved.
Only for training and service purposes.
SPECIFICATIONS
• GENERAL
Power requirements 25 V 1.52 A (AC adapter)
Power consumption Refer to the main label on the unit.
Networked standby : 5.0 W (If all network ports are activated.)
AC adapter Model : DA-38A25
Manufacturer : Asian Power Devices Inc.
Input : 100 - 240 V ~ 50 - 60 Hz
Output : 25 V 1.52 A
Dimensions (W x H x D) Approx. 1220 mm x 38 mm x 105 mm (with foot)
Operating temperature 5 °C to 35 °C
Operating humidity 5 % to 90 %
Available Digital Input Audio
Sampling Frequency 32 kHz, 44.1 kHz, 48 kHz, 88.2 kHz, 96 kHz
Available Digital Input Audio format Dolby Audio, DTS Digital Surround, PCM
• INPUT/OUTPUT
OPTICAL IN 3 V (p-p), Optical jack x 1
HDMI IN 19 Pin (Type A, HDMI™ connector) x 1
HDMI OUT 19 Pin (Type A, HDMI™ connector) x 1
4K Sources dependent on HDCP 2.2 are supported at 4K resolutions.
• AMPLIFIER (RMS Output)
Total 300 W RMS
Front 65 W RMS x 2 (4 Ω at 1 kHz, THD 10%)
Subwoofer 170 W RMS (3 Ω at 80 Hz, THD 10%)
• WIRELESS SUBWOOFER
Power requirements Refer to the main label on the subwoofer.
Power consumption 33 W
Type 1 Way 1 Speaker
Impedance 3 Ω
Rated Input Power 170 W RMS
Max. Input Power 340 W RMS
Dimensions (W x H x D) Approx. 171 mm x 320 mm x 252 mm
• SYSTEM
LAN port Ethernet jack x 1, 10 BASE-T/100 BASE-TX
Wireless LAN (Internal antenna) Integrated IEEE 802.11n (Draft 2.0) wireless networking access,
compatible with 802.11a/b/g/n Wi-Fi networks.
• Designs and specifications are subject to change without prior notice.
