ASSEMBLING AND PREPARING
Parts and Components
Front Panel
Back Panel
HDMI OUT LAN
DIGITAL
AUDIO
AV IN IR IN POWER
ANTENNA/
CABLE IN
AUDIO
LINE OUT
SERVICE
DISPLAY
CONTROL 1
DISPLAY
CONTROL 2
MPI HDMI IN 2
(ARC)
HDMI IN 1
USB IN 1 USB IN 2
ARC (Audio Return Channel)
• When connected with a high-speed HDMI cable, digital audio can be sent to a compactible device
without an additional optical audio cable.
• ARC is only supported on the HDMI input 2 port. An external audio device that supports ARC should
be connected to HDMI IN 2 (ARC) if you wish to use ARC.
