EXPLODED VIEW PARTS LIST
Description
CABINET ASSEMBLY, 900BJ BRAND TKC057 “A” - DI LOCAL - For World Wide
CABINET ASSEMBLY, 900BJ BRAND TKC057A LIFE GOOD (DI-LOCAL) - For Australia
CABINET ASSEMBLY, 900BJ BRAND TKC057A LOGO RED (DI-LOCAL) - For Panama
CDT(CIRC), M46QCG913X 13NPUD LG-PHILIPS DISPLAYS 95KHZ 29.1 MM - For Northern Hemisphere, Eguatorial
CDT(CIRC), M46QCG913X 13SPUD LG-PHILIPS 95KHZ 29.1MM FST - For Southern Hemisphere
CDT(CIRC), M46QCG913X 14KPUD LG-PHILIPS 95KHZ 29.1MM FST TCO - For India
BACK COVER ASSEMBLY, EB990G 036A 85964 [NT CKD] PFC - For Eurore
BACK COVER ASSEMBLY, CB997G TKC036-85864 NON PFC [A-CKD] - For World Wide
TILT SWIVEL ASSEMBLY, EB990G TKB048/TKT054 [NT CKD] 85964
SCREW ASSY, PHP+5*20(FZMY)+GW18 NEW TYPE
COIL,DEGAUSSING, 1290MM 16.5OHM 0.45MM 115T 19” CB997E
FBT (FLY BACK TRANSFORMER), FQM19A013,T910BJ(98K) SAMSUNG 19”
FILTER(CIRC),EMC, 02MD5 DELTA BK F900BJ
CABLE,D-SUB, UL20276-9C(5.8MM) AT 1560MM GRAY(85964) T910BJ DM
METAL, REAR EB990G [NT,”A” CKD]
HOLDER, PCB FIX , PC+ABS
METAL ASSEMBLY, SHIELD BOTTOM “E”-CKD
PWB(PCB) ASSEMBLY,SUB, CB997G CONTROL TOTAL BRAND CA-123
SHIELD ASSEMBLY, TOP T910BJ [“C”-CKD]
PWB(PCB) ASSEMBLY,MAIN, 900BJ KLRUED BRAND CA-130 TOTAL - For Europe
PWB(PCB) ASSEMBLY,MAIN, 900BJ KLIDED BRAND CA-130 TOTAL - For World Wide
PWB(PCB) ASSEMBLY,MAIN, 900BJ KLINED BRAND CA-130 TOTAL - For India
MAIN TOTAL ASSEMBLY, 900BJ BRAND CA-130 - For Europe
MAIN TOTAL ASSEMBLY, 900BJ BRAND CA-130 - For World Wide
MAIN TOTAL ASSEMBLY, 900BJ BRAND CA-130 - For India
Ref. No.
1
2
3
4
5
6
7
8
9
10
11
12
13
14
A
B
Part No.
3091TKC065H
3091TKC065K
3091TKC065J
2423GG2E92E
6318L19003A
6318L19003C
3809TKC038J
3809TKC038K
3043TKK079D
339-002H
6140TC4002A
6174T13010K
6200TJB001N
6850TA9009N
4950TKK292B
4930TKK031C
4951TKK108F
6871TST311C
4815TKT017D
6871TMT468B
6871TMT468A
6871TMT468D
3313T19060B
3313T19060A
3313T19060D
To Next Page
