DATE: 2003. 7. 4.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
Q806 0TR471009AA KSD471AC-Y TP SAMSUNG TO92
Q807 0TR564009AB KSB564AC-YTA TP SANSUNG TO92
Q808 0TR127009AA KTA1270-Y(KTA562TM) TP KEC T
Q810 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q811 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5
Q812 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q832 0TF283509AA 2SK2835(TP) TP TOSHIBA 200V
Q833 0TFFC10008A SFS9634 FAIRCHILD ST TO220F
Q834 0TR231609AA KSC2316-Y TP SAMSUNG TO92L
Q836 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5
Q837 0TF630000CA IRFS630A BK SAMSUNG 200V 6.5
Q839 0TF640000CA IRFS640A BK SAMSUNG 200V 9A
Q841 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q842 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q844 0TR114009AB DTC114ES TP ROHM-K SPT NPN
Q901 0TFFN10003C INFINEON SPA07N60C3(E8153) S
Q902 0DR100609BA MCR100-6RLRA TP MOTOROLA TO9
Q903 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q912 0TR127309AA KTA1273-Y(KTA966A) TP KEC TO
Q913 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q914 0TR928009AB KSA928A-Y TP SAMSUNG TO92L P
Q915 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
Q920 0TR319809AA KTC3198-Y(KTC1815) TP KEC TO
R201 0RD1001Q609 1K 1/4W(3 5% TA52
R202 0RD1600Q609 160 1/4W(3 5% TA52
R203 0RD2200Q609 220 1/4W(3 5% TA52
R204 0RD2200Q609 220 1/4W(3 5% TA52
R205 0RD1001Q609 1K 1/4W(3 5% TA52
R206 0RD1600Q609 160 1/4W(3 5% TA52
R207 0RD3300Q609 330 1/4W(3 5% TA52
R208 0RD3300Q609 330 1/4W(3 5% TA52
R209 0RD5600Q609 560 1/4W(3 5% TA52
R210 0RD3600Q609 360 1/4W(3 5% TA52
R211 0RD5100Q609 510 1/4W(3 5% TA52
R301 0RD0752Q609 75 1/4W(3 5% TA52
R302 0RD0752Q609 75 1/4W(3 5% TA52
R303 0RD0752Q609 75 1/4W(3 5% TA52
R305 0RN6201F409 6.20K 1/6W 1% TA52
R306 0RD1002Q609 10K 1/4W(3 5% TA52
R307 0RD5102Q509 51K OHM 1/4 W (3.4) 2% TA52
R308 0RD1002Q609 10K 1/4W(3 5% TA52
R314 0RD1000Q609 100 1/4W(3 5% TA52
R315 0RD1000Q609 100 1/4W(3 5% TA52
R319 0RD8201Q609 8.20K 1/4W(3 5% TA52
R320 0RD4701Q609 4.70K 1/4W(3 5% TA52
R326 0RD4701Q609 4.70K 1/4W(3 5% TA52
R327 0RD2001Q609 2K 1/4W(3 5% TA52
R328 0RD2001Q609 2K 1/4W(3 5% TA52
R329 0RD2001Q609 2K 1/4W(3 5% TA52
R330 0RD1000Q609 100 1/4W(3 5% TA52
R331 0RD1600Q609 160 1/4W(3 5% TA52
R332 0RD1800Q609 180 1/4W(3 5% TA52
R333 0RD1500Q609 150 1/4W(3 5% TA52
R334 0RD3303Q609 330K 1/4W(3 5% TA52
R335 0RD3303Q609 330K 1/4W(3 5% TA52
R336 0RD3303Q609 330K 1/4W(3 5% TA52
R337 0RD3000Q609 300 1/4W(3 5% TA52
R340 0RN1002F409 10K 1/6W 1 TA52
R341 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
DATE: 2003. 7. 4.
*S *AL LOC. NO. PART NO. DESCRIPTION / SPECIFICATION
R342 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R343 0RD0332A609 33 OHM 1/2 W (7.0) 5% TA52
R344 0RD0332Q609 33 1/4W(3 5% TA52
R345 0RD0332Q609 33 1/4W(3 5% TA52
R346 0RD0332Q609 33 1/4W(3 5% TA52
R347 971-0016 TIN HDC 0.60H
R401 0RD3300Q609 330 1/4W(3 5% TA52
R402 0RD1000Q609 100 1/4W(3 5% TA52
R403 0RD4701Q609 4.70K 1/4W(3 5% TA52
R405 0RD4701Q609 4.70K 1/4W(3 5% TA52
R406 0RD4701Q609 4.70K 1/4W(3 5% TA52
R407 0RD1000Q609 100 1/4W(3 5% TA52
R412 0RD1000Q609 100 1/4W(3 5% TA52
R413 0RD2202Q609 22K 1/4W(3 5% TA52
R414 0RD2202Q609 22K 1/4W(3 5% TA52
R415 0RD2202Q609 22K 1/4W(3 5% TA52
R416 0RD2202Q609 22K 1/4W(3 5% TA52
R418 0RD2000Q609 200 1/4W(3 5% TA52
R419 0RN1002F409 10K 1/6W 1 TA52
R420 0RD4701Q609 4.70K 1/4W(3 5% TA52
R421 0RD1001Q609 1K 1/4W(3 5% TA52
R422 0RD4701Q609 4.70K 1/4W(3 5% TA52
R423 0RD1000Q609 100 1/4W(3 5% TA52
R425 0RD2001Q609 2K 1/4W(3 5% TA52
R426 0RD2001Q609 2K 1/4W(3 5% TA52
R428 0RD1000Q609 100 1/4W(3 5% TA52
R429 0RD1000Q609 100 1/4W(3 5% TA52
R430 0RD1801Q609 1.80K 1/4W(3 5% TA52
R431 0RD1801Q609 1.80K 1/4W(3 5% TA52
R432 0RD1301Q609 1.30K 1/4W(3 5% TA52
R434 0RN1002F409 10K 1/6W 1 TA52
R440 0RD1000Q609 100 1/4W(3 5% TA52
R443 0RD1001Q609 1K 1/4W(3 5% TA52
R451 0RD4701Q609 4.70K 1/4W(3 5% TA52
R452 0RD4701Q609 4.70K 1/4W(3 5% TA52
R453 0RD1500Q609 150 1/4W(3 5% TA52
R454 0RD6201Q609 6.20K 1/4W(3 5% TA52
R456 0RD0622A609 62 OHM 1/2 W (7.0) 5% TA52
R461 0RX0472J609 47 OHM 1 W 5% TA52
R462 0RD0102A609 10 OHM 1/2 W (7.0) 5% TA52
R463 0RD6801Q609 6.80K 1/4W(3 5% TA52
R464 0RN1000F409 100OHM 1/6 W 1% TA52
R465 0RN6202F409 62KOHM 1/6 W 1% TA52
R466 0RD4302Q609 43K 1/4W(3 5% TA52
R467 0RN5601F409 5.60K 1/6W 1% TA52
R473 0RD1004Q609 1M OHM 1/4 W (3.4) 5% TA52
R493 0RD1000Q609 100 1/4W(3 5% TA52
R494 0RD1000Q609 100 1/4W(3 5% TA52
R601 0RD2001Q609 2K 1/4W(3 5% TA52
R602 0RD2001Q609 2K 1/4W(3 5% TA52
R603 0RD0111A509 1.1 OHM 1/2 W(7.0) 2% TA52
R604 0RD0331A609 3.3 OHM 1/2 W (7.0) 5% TA52
R605 0RN1302F409 13K 1/6W 1% TA52
R606 0RN1302F409 13K 1/6W 1% TA52
R607 0RD1500A609 150 OHM 1/2 W (7.0) 5% TA52
R608 0RD1000Q609 100 1/4W(3 5% TA52
R609 0RD1000A609 100 OHM 1/2 W (7.0) 5% TA52
R610 0RN0390H609 0.39 1/2W 5 TA52
R701 0RMZTWD001C 47 OHM 7 W 5% RWR PD-TYPE
R702 0RD1002Q609 10K 1/4W(3 5% TA52
R703 0RD3301Q609 3.30K 1/4W(3 5% TA52
R704 0RD2201Q609 2.20K 1/4W(3 5% TA52
- 26 -
RESISTORs
