Installing the Drain Hose
• The drain hose should not be placed higher
than 100 cm above the floor. Water in the
appliance may not drain or may drain slowly.
1
Insert the band clamp onto the drain hose
elbow.
Band clamp
2
With the hose leading up from the elbow,
insert the elbow onto the drain outlet on the
back of Mini Washer.
3
Adjust the band clamp with pliers to keep
the hose securely in place and prevent
leaking.
Band clamp
Using the Drain Hose Connector
1
Insert the band clamps into the end of the
Main and Mini Washer’s drain hose.
2
Attach each drain hose to the double drain
hose connector and tie them with the band
clamps.
3
Insert the drain hose connector into the
drain pipe/hole.
Drain hose
connector
Please follow the following steps if you have
the drain connectors on the wall (no drain
pipe/hole).
4
Using the connecting drain hose's band
clamp, connect it to the remaining hole of
the drain hose connector.
5
Attach the connecting drain hose to the
drain connector on the wall.
