MULTI F OUTDOOR UNIT | 17
Multi F Outdoor Unit Data
'XHWRRXUSROLF\RIFRQWLQXRXVSURGXFWLQQRYDWLRQVRPHVSHFL¿FDWLRQVPD\FKDQJHZLWKRXWQRWL¿FDWLRQ
©/*(OHFWURQLFV86$,QF(QJOHZRRG&OLIIV1-$OOULJKWVUHVHUYHG³/*´LVDUHJLVWHUHGWUDGHPDUNRI/*&RUS
MULTI
F
MAX
MULTI
F
General Data
MULTI F OUTDOOR UNIT
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU18CHV
Non-Ducted
Indoor Units
17,000 13.0 22.0 22,000 3.2 9.7 13,500 2.4
Ducted Indoor Units 14,000 10.7 17.2 19,800 2.9 9.7 13,000 2.4
Mixed Non-Ducted and
Ducted Indoor Units
15,500 11.8 19.6 20,900 3.0 9.7 13,250 2.4
Table 9: /08+9(I¿FLHQF\5DWLQJV
1,2
Table 10: /08&+9(I¿FLHQF\5DWLQJV
1,2
Table 11: /08+9(I¿FLHQF\5DWLQJV
1,2
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU240HV
Non-Ducted
Indoor Units
23,600 13.5 22.5 24,600 4.20 11.0 15,200 2.89
Ducted Indoor Units 22,000 12.5 18.5 23,000 3.47 9.8 14,500 2.64
Mixed Non-Ducted and
Ducted Indoor Units
22,800 13.0 20.5 23,800 3.81 10.4 14,850 2.76
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU180HV
Non-Ducted
Indoor Units
18,000 13.5 22.5 22,000 3.60 11.0 14,500 2.66
Ducted Indoor Units 17,200 12.5 18.5 20,000 3.27 9.6 13,000 2.47
Mixed Non-Ducted and
Ducted Indoor Units
17,600 13.0 20.5 21,000 3.43 10.3 13,750 2.57
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU24CHV
Non-Ducted
Indoor Units
20,000 13.5 21.7 24,000 3.9 10.6 14,500 2.7
Ducted Indoor Units 17,800 11.5 17.5 22,500 3.4 9.8 14,000 2.5
Mixed Non-Ducted and
Ducted Indoor Units
18,900 12.5 19.6 23,250 3.7 10.2 14,250 2.6
Table 12: /08&+9(I¿FLHQF\5DWLQJV
1,2
1
Rated capacity is rated 0 ft. above sea level with 25 ft. of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor
units. All capacities are net with a combination ratio between 95 – 105%.
Rated cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb (WB) and outdoor ambient conditions
of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Rated heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet bulb (WB) and outdoor ambient conditions
of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
2
5DWHGFDSDFLW\LVFHUWL¿HGXQGHU$+5,6WDQGDUG((5,((5&23DQG+63)DUHVXEMHFWWRFKDQJH6HHZZZDKULQHWRUJIRUWKHODWHVW
values.
At least two indoor units must be connected. For allocated capacity information, see the combination tables in the "Multi F / Multi F MAX Combina-
tion Data Manual" on www.lghvac.com. For performance data, see "Multi F / Multi F MAX Performance Data Manual" on www.lghvac.com.
