18 | MULTI F OUTDOOR UNIT
Multi F and Multi F MAX Heat Pump System Engineering Manual
MULTI
F
MAX
MULTI
F
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU36CHV
Non-Ducted
Indoor Units
32,000 13.0 22.0 36,000 3.9 10.0 20,000 2.6
Ducted Indoor Units 28,000 11.0 18.2 34,000 3.5 9.7 19,500 2.4
Mixed Non-Ducted and
Ducted Indoor Units
30,000 12.0 20.1 35,000 3.7 9.9 19,750 2.5
1
Rated capacity is rated 0 ft. above sea level with 25 ft. of refrigerant line per indoor unit and a 0 ft. level difference between outdoor and indoor
units. All capacities are net with a combination ratio between 95 – 105%.
Rated cooling capacity rating obtained with air entering the indoor unit at 80ºF dry bulb (DB) and 67ºF wet bulb (WB) and outdoor ambient conditions
of 95ºF dry bulb (DB) and 75ºF wet bulb (WB).
Rated heating capacity rating obtained with air entering the indoor unit at 70ºF dry bulb (DB) and 60ºF wet bulb (WB) and outdoor ambient conditions
of 47ºF dry bulb (DB) and 43ºF wet bulb (WB).
2
5DWHGFDSDFLW\LVFHUWL¿HGXQGHU$+5,6WDQGDUG((5,((5&23DQG+63)DUHVXEMHFWWRFKDQJH6HHZZZDKULQHWRUJIRUWKHODWHVW
values.
System Combined With
Rated Cooling
Capacity (Btu/h)
EER
(95°F)
SEER
Rated Heating
Capacity (Btu/h)
COP
(47°F)
HSPF
Low Heating
Capacity (Btu/h)
COP
(17°F)
LMU30CHV
Non-Ducted
Indoor Units
30,000 13.0 22.0 32,000 3.8 10.0 19,600 2.7
Ducted Indoor Units 27,400 11.0 18.2 33,000 3.5 9.7 19,000 2.5
Mixed Non-Ducted and
Ducted Indoor Units
28,700 12.0 20.1 32,500 3.6 9.85 19,300 2.6
At least two indoor units must be connected. For allocated capacity information, see the combination tables in the "Multi F / Multi F MAX Combina-
tion Data Manual" on www.lghvac.com. For performance data, see "Multi F / Multi F MAX Performance Data Manual" on www.lghvac.com.
Table 13: /08&+9(I¿FLHQF\5DWLQJV
1,2
Table 14: /08&+9(I¿FLHQF\5DWLQJV
1,2
