7
Connecting Hose to Appliance
Pump Model
Attach the hot water line to the hot water inlet
on the back of the washing machine. Attach the
cold water line to the cold water inlet on the
back of the washing machine.
NOTE
NOTE
ҟAfter completing connection, if water leaks
from the hose, repeat the same steps. Use
the most conventional type of tap for the water
supply. In case the tap is square or too big,
remove the guide plate before inserting the
tap into the adaptor.
Before connecting the drain hose, check your
drain hose model and choose the correct
instruction.
35" ~ 47" ( 0.9~ 1.2m)
Cable Tie
Cable Tie
35" ~ 47" ( 0.9~ 1.2m)
Connect the drain hose to the outlet of the drain
pump located at the rear of the washing machine.
Attach the clip to the drain hose.
And then push it toward the body of the washing
machine as indicated by the arrow.
The drain hose should always be
properly
secured to the drain or standpipe. Failure to
secure
the drain hose properly can result in flooding and
property damage.
The end of the drain hose should be placed 39"
(99 cm) above the floor.
The drain must be installed in accordance with
any applicable local codes and regulations.
Mak
e sure that the water lines are not stretched,
pinched, crushed, or kinked.
Do not insert the drain hose more than 12” (30
cm) into the drain pipe to avoid siphoning and
odor build-up.
Check that the drain hose is hung up over the
edge of the laundry tub.
Do
not use an extension hose.
2-3. Installing the Drain Hose
