30
3 - START-UP AND THREADING
• Wind the wire around the feeding wheel as shown in the figures, taking ca-
re that the first coil is run below the separation pin, whereas for the fol-
lowing coils the yarn shall run on top of it. (A)
• Apply the yarn to the yarn guide bush so that the yarn runs above the load
cell. At this point, in cases when the self-restore threading option is ena-
bled, operation will be automatically restored, otherwise press any button
to restore the device to operation. (B)
The number of coils to be wound around the feeding wheel varies as a func-
tion of the yarn type. The following values are provided as an indication:
− plain Lycra: 1-2 coils
− coated Lycra, cotton, nylon and polyester: 3-5 coils.
AB
