43
SWITCH 3: “TE-Tension Error” ALARM POSITION
0 = ENABLED ON T1 ONLY
1 = ENABLED ON T1 AND T2
It defines the work position (defined by the INC/DEC signal state) where the
Tension Error alarm is enabled, namely where it is ready to operate in cases
when Tension exceeds the limit range.
N.b.:
− This option does not set the position where the alarm is released,
it only sets the position where it gets ready to operate.
− Please consider that the T1 position as to the INC/DEC signals de-
pends on how the option “AO-0 - INC/DEC SIGNAL POLARITY” is set.
SWITCH 4: “TE-Tension Error” ALARM RESET
0 = AUTO
1 = MANUAL
It defines whether the Tension Error alarm must be automatically released
when the tension falls back into the range set for the “TE-Tension Error”
parameter, or has to be manually released via the ESC button or upon
indication of the dedicated command on the INC & DEC inputs.
AO-3
- “TE” ALARM POSITION = 0
T1
The Tension Error is only enabled in T1, not in T2.
AO-3
- “TE” ALARM POSITION = 1
T1 & T2
The Tension Error is enabled in both T1 and T2.
AO-4
- “TE” ALARM RESET = 0
AUTO
It automatically leaves the “Tension Error” alarm state
When tension falls back into the range.
AO-4
- “TE” ALARM RESET = 1
MANUAL
It only leaves the “Tension Error” alarm state by
pressing the ESC button on the display unit or via the
indication from the reset command on the INC & DEC
signals.
N.b.: the reset command on the INC/DEC signals
depends on the way the AO-5 and AO-6 options
are set.
4 - SETTING THE OPERATING PARAMETERS
