Chapter 9 - Operating instructions
9.14 Extending and retracting the platform
The protective rail system of the platform consists of a collapsible protective rail part of the extended platform and a
collapsible protective rail of the main platform. All parts are tted via eight steel locking pins.
1) The platform is completely reduced in size, extendable platform has been retracted and platform controls have
been removed.
2) From the inside of the platform, two wire locking pins on the upper part of the front safety rail of the
expansion platform have been removed.
3) Tilt the front protective rail of the expansion platform, do not place your hands in a place that could possibly
cause injury.
4) Install two disassembled steel wire locks back on each side of the guardrail support.
5) Remove two wire locks in the middle of the left guardrail and turn the left guardrail of the extended platform
inwards. Do not place your hand where it could be injured.
6) Place two disassembled wire locking pins on the safety bar.
7) Remove two wire locks in the centre of the right protective rail and turn the right protective rail of the
extended platform inwards. Do not place your hand where it could be injured.
8) Place two disassembled wire locking pins on the safety bar.
9) Remove the wire lock from the top guardrail of the door and turn the top guardrail in. Do not place your hand
where it could be damaged.
10) Place two disassembled wire locking pins on the safety bar.
11) Remove the wire lock from the upper left guardrail of the platform and turn the left guardrail inwards. Do not
place your hand where it could be damaged.
12) Place two disassembled wire locking pins on the safety bar.
13) Remove the wire lock from the upper right guardrail of the platform and turn the right guardrail inwards.
Do not place your hand where it could be damaged.
14) Place two disassembled wire locking pins on the safety bar.
9.15 Folding the protective rail
Follow the folding instructions for the protective rail and perform the installation in reverse order.
9.16 Extending and retracting the platform
1) Step on the locking pedal on the extended platform.
2) Push the protective rail of the extended platform to bring it to the desired position.
Notice: do not stand on the extended platform when the platform is extended.
