LGMG AS0607 - Inspection of Tyres and Rims; Emergency Stop Inspection

USER MANUAL - SS0407E / SS0507E / SS0607E / AS0607 / AS0607W / AS0607WE / AS0607E / AS0608 / AS0608E
47
Chapter 11 - Maintenance
5) Lift the safety support, move it to the centre of the scissors housing and turn it upwards until it's vertical.
6) Lower the platform height until the safety support is completely against the shaft housing.
Risk of crushing
Place your hand on the correct position of the safety support when lowering the platform.
7) Check whether there is a burnt, damaged, eroded, bent and loose cable in the chassis and scissor area.
8) Check whether there is a burnt, damaged, eroded, bent and loose cable in the following areas:
• cable or scissor arm
• ECU at the platform
• case connector connected to the platform
9) Check the open coating of the insulating sheath at the positions below:
• case connector connected between the ECU and the platform controller
• all case connectors connected to the level sensor
10) Raise the platform and restore the safety support to the installation position.
11) Lower the platform to the retracted position and then turn off the machine.
B-3 Inspection of tyres and rims
This check must be carried out every 250 hours or every quarter, whichever comes rst.
Keeping the tyre and rim in good condition is essential for safe handling and good performance.
The failure of a tyre or rim can lead to machine tilting. The machine elements can also be damaged if the defective
tyres and rims are not detected and repaired.
1) Check that the tyre tread and sides are not damaged, cracked or punctured, have holes and other abnormal
wear and tear.
2) Check if the rim is damaged, bent and torn. Model suitable for hydraulic control
3) Remove the locknut and check the nut torque.
Notice: A new locknut must be used when reassembling the tyre and rim.
4) Install and lock a new locknut.
Model suitable for electric control
5) Check the torque of each bolt
B-4 Emergency stop inspection
1) This check must be carried out every 250 hours or every quarter, whichever comes rst.
2) The normal emergency stop function is essential for the safe operation of the machine. It is not possible to
switch off the power supply and stop all functions of the machine with the special red
Emergency stop button. A Dangerous situation can be caused in such a case.
3) As a safety function, in addition to the red emergency stop button on the platform, the selection and
operation of the ground controls must be superior to those of the platform controls.
Couple
Lubrication-free nut 410-540N
90NLubrication-free bolt
