Elevating Work Platform Operation Manual
49
Specifications
Parameters of SR1623D (S16230NDCH21) Whole Machine
Performance Parameters of Whole Machine
Item
Parameters
Item
Parameters
Rated load (kg)
680
Running height (m)
8.5
Recommended load capacity of
extension deck (kg)
230
Ascending/descending
speed (s)
55/55
Maximum number of workers
4
Minimum turning radius
(inner wheel) (m)
2.57
Maximum working height (m)
18
Minimum turning radius
(outer wheel) (m)
5.33
Maximum platform height (m)
16
Maximum allowable angle
of operation (front and rear)
3°
Extension dimension of front
platform (m)
1.45
Maximum allowable angle
of operation (left and right)
2°
Extension dimension of rear
platform
1.14
Maximum leveling angle of
outrigger (from front to rear)
7°
Running speed of machine
(folding state) (km/h)
6.1
Maximum leveling angle of
outrigger (from left to right)
12°
Running speed of machine (rising
state) (km/h)
1.1
Theoretical climbing ability
(mm)
40%
Main Dimensions
Item
Parameters
Item
Parameters
Length of whole machine -
platform retraction (m)
4.9
Height of platform - whole vehicle
storage (m)
2.08
Width of whole machine (m)
2.3
Wheel base (front/rear) (mm)
2,850
Height of whole machine -
unfolded guard railing (m)
3.18
Thread (mm)
1,993
Height of whole machine -
folded guard railing (m)
2.5
Ground clearance (folding state)
(m)
0.23
Dimension of main platform
(length × width) (m)
3.98×1.83
Tire specification (diameter ×
width)
835×290
Extension length - single
extension length (m)
5.44
Weight of whole machine (kg)
8,000
Extension length - double
extension length (m)
6.58
Main Dimensions-7.2m platform (If equipped)
Item
Parameters
Item
Parameters
Length of whole machine -
platform retraction (m)
4.9
Height of platform - whole vehicle
storage (m)
2.08
Width of whole machine (m)
2.3
Wheel base (front/rear) (mm)
2,850
Height of whole machine -
unfolded guard railing (m)
3.18
Thread (mm)
1,993
Height of whole machine -
folded guard railing (m)
2.5
Ground clearance (folding state)
(m)
0.23
