Elevating Work Platform Operation Manual
50
Dimension of main platform
(length × width) (m)
4.61×1.83
Tire specification (diameter ×
width)
835×290
Extension length - single
extension length (m)
6.07
Weight of whole machine (kg)
8060
Extension length - double
extension length (m)
7.21
Engine System
Item
Parameters/Contents
Item
Parameters/Contents
Model
D2011L03i
Number of cylinder
3
Rated power
(/KW)
36.3
Type
In-line, Air-cooling and
four-stroke
Rated speed
(r/min)
2,800
Maximum torque
(N.m)/speed (r/min)
137/1,700
Displacement (ml)
2,331
Emission standard
EU3
Hydraulic System
Item
Parameters/Contents
Type
Open lifting system and closing
walking system
Lifting pump
Gear pump with displacement of
16 ml/r
Walking pump
Closed variable pump with
displacement of 49 ml/r
System pressure (MPa)
28
Walking motor
Piston motor with displacement
of 38 ml/r
Refueling Volume
Item
Parameters
Hydraulic oil
140 L (replacement of oil)
Engine oil （CH-4 15W-40）
9.5L
Diesel
110L
Reducer (4) 80-90/w
0.68L*4
Note: When hydraulic oil and diesel are filled, it is necessary to use the corresponding hydraulic oil
and diesel according to operating environment and temperature, and refer to the following contents:
 L-HM 46 antiwear hydraulic oil: minimum air temperature＞-9℃;

L-HV 46 low temperature hydraulic oil: -33℃＜minimum air temperature≤-9℃;
 L-HS 46 Ultralow temperature hydraulic oil: -39℃＜minimum air temperature≤-33℃

10# aviation hydraulic oil: minimum air temperature ≤-39℃;
Engine oil type(15W-40). Engine oil type-cold condition(5W-30).
